MIL-DTL-23928 MILITARY DISTRIBUTION PANELS
WE CAN CROSS REFERENCE MOST PART NUMBERS
ALB-1 Panels VIEW
PANEL TYPE MIL.SPEC. SYMBOL NO.
DP TE WT CKTS
ALB-1 M23928/1-00 994.3 4/1 PH
ALB-1 M23928/1-01 994.4 994.5 994.6 6/1 PH
ALB-1 M23928/1-02 995.4 995.5 995.6 8/1 PH
ALB-1 M23928/1-03 999.4 999.5 999.6 12/1 PH
ALB-1 M23928/1-04 1006 1006.1 1006.2 14/1 PH
ALB-1 M23928/1-05 1007 1007.1 1007.2 18/1 PH
ALB-1 M23928/1-06 1008 1008.1 1008.2 24/1 PH
ALB-1 M23928/1-11 1009 1009.1 1009.2 4/3 PH
ALB-1 M23928/1-12 1010 1010.1 1010.2 6/3 PH
ALB-1 M23928/1-13 1011 1011.1 1011.2 8/3 PH
ALB-1 M23928/1-14 1012 1012.1 1012.2 10/3 PH
ALB-1 M23928/1-15 1013 1013.1 1013.2 12/3 PH
ALB-1 M23928/1-16 1014 1014.1 1014.2 14/3 PH
AQB-A50 Panels VIEW
PANEL TYPE MIL.SPEC. SYMBOL NO.
DP TE WT CKTS
AQB-A50 M23928/2-01 2494.3 2494.4 2494.5 2
AQB-A50 M23928/2-02 2495.3 2495.4 2495.5 4
AQB-A50 M23928/2-03 2496.3 2496.4 2496.5 6
AQB-A50 M23928/2-04 2497.3 2497.4 2497.5 8
AQB-A50 M23928/2-05 2498.3 2498.4 2498.5 10
AQB-A50 M23928/2-06 2499.3 2499.4 2499.5 12
AQB-A50 M23928/2-07 2499.6 2499.7 2499.8 14
AQB-A50 M23928/2-08 2499.9 2499.10 2499.11 16
AQB-A101 Panels VIEW
PANEL TYPE MIL.SPEC. SYMBOL NO.
DP TE WT CKTS
AQB-A101 M23928/3-01 2508 2508.1 2508.2 1
AQB-A101 M23928/4-01 2521 2521.1 2521.2 2
AQB-A101 M23928/4-02 2522.2 2522.3 2522.4 4
AQB-A101 M23928/4-03 2523.2 2523.3 2523.4 6
AQB-A101 M23928/4-04 2531.2 2531.3 2531.4 8
AQB-A101 M23928/4-05 2532.2 2532.3 2532.4 10
AQB-A101 M23928/4-06 2533.2 2533.3 2533.4 12
DISTRIBUTION PANEL WITH TWO NQB-A101 CIRCUIT BREAKERS FOR TWO-WAY 100A BUS TRANSFER VIEW
PANEL TYPE MIL.SPEC. SYMBOL NO.
DP TE WT CKTS
AQB-A101 M23928/4-11 2511 2511.1 2511.2 4
AQB-A101 M23928/4-12 2511.3 2511.4 2511.5 6
AQB-A101 M23928/4-13 2511.6 2511.7 2511.8 8
AQB-A101 M23928/4-14 2511.9 2511.10 2511.11 10
AQB-A101 M23928/4-15 2511.12 2511.13 2511.14 12
DISTRIBUTION PANEL WITH THREE NQB-A101 CIRCUIT BREAKERS FOR THREE-WAY 100A BUS TRANSFER
PANEL TYPE MIL.SPEC. SYMBOL NO.
DP TE WT CKTS
AQB-A101 M23928/4-21 2512 2512.1 2512.2 4
AQB-A101 M23928/4-22 2512.3 2512.4 2512.5 6
AQB-A101 M23928/4-23 2512.6 2512.7 2512.8 8
AQB-A101 M23928/4-24 2512.9 2512.10 2512.11 10
DISTRIBUTION PANEL WITH TWO NQB-A250 CIRCUIT BREAKERS FOR TWO-WAY 250A BUS TRANSFER
PANEL TYPE MIL.SPEC. SYMBOL NO.
DP TE WT CKTS
AQB-A101 M23928/4-31 2513 2513.1 2513.2 4
AQB-A101 M23928/4-32 2513.3 2513.4 2513.5 6
AQB-A101 M23928/4-33 2513.6 2513.7 2513.8 8
AQB-A101 M23928/4-34 2513.9 2513.10 2513.11 10
AQB-A101 M23928/4-35 2513.12 2513.13 2513.14 12
DISTRIBUTION PANEL FOR AQB-A250 OR NQB-A250
CIRCUIT BREAKERS VIEW
PANEL TYPE MIL.SPEC. SYMBOL NO.
DP TE WT CKTS
AQB-A250 M23928/6-01 2472.1 2472.2 2472.3 1
AQB-A250 M23928/7-01 2473.2 2473.3 2473.4 2
DISTRIBUTION PANELS WITH MANUAL BUS TRANSFER
PANEL TYPE MIL.SPEC. SYMBOL NO.
DP TE WT CKTS
NQB-A101 M23928/5-01 2471 2471.1 2471.2 2
NQB-A250 M23928/8-01 2474.2 2472.3 2474.4 2
CUSTOM MADE DISTRIBUTION PANELS AVAILABLE ON REQUEST
